The molded trough bridge is a new type of cable support solution designed for modern electrical installation and cable management. It is based on high-quality cold-rolled steel strips and is formed by advanced mechanical molding technology, combining the dual advantages of molded bridges and trough bridges.
The product has the characteristics of high strength, lightweight, corrosion resistance, and flexible installation. Its unique trough design not only provides neat and orderly cable arrangement, but also greatly reduces the confusion and interweaving of cables, making cable wiring clearer and easier to manage. At the same time, the corrugated bottom plate structure of the molded trough bridge increases the heat dissipation area, helps to reduce the resistivity of the cable, reduce losses, and achieve cost reduction and energy saving.
The molded trough bridge is widely used in a variety of scenarios such as commercial complexes, schools, hotels, residences and factories, and is suitable for installation environments such as underground garages, ceilings, wire wells, and pipe galleries. Its modular design and easy construction make the installation and adjustment process simple and quick, greatly reducing construction costs and time.
| Type | Through type | |
| Material | Material | Steel、 Aluminum、ss304、ss316L |
| Surface finishing/treatment |
Pre-galvanized 8um/ Electro zinc Plating（≥12um） Hot -dip galvanized（＞60um） Plastic-spayed（＞60um） Power coating Acid washing +polishing （option） |
|
|
Dimension range customizable is available |
Width | 50/100/150/200/250/300mm |
| Side Rail Height | 25/50/75/100/150mm | |
| Length | ||
| Thickness/wire diameter | 0.8/1/1.2mm | |
| Max. Working Load | According To Size | |
| Accessories/related products | ||
| Product Features | Fullv enclosed cable travs are effective in shielding control cables from interference and protecting cables in highly corrosive environments. |
|
| Color | Sliver or others/According to customers | |
| Enviroment demmand | Indoor&dry normal temperature light anti-corrosion&outside wet high temperature&heavy corrosion&dry normal temperature | |
| Application | Oil gas、chemical、ships、building、infransture | |
